New Japan Radio NJT8304N 4W Standard Ku-Band BUC

NJRC NJT8304N 4W Universal Ku-Band BUC Output Frequency Range: 14.0 - 14.5 GHz L.O. Frequency: 13.05 GHz IF Input Frequency: 950 - 1,700 MHz Output Power @ P1dB: +36.0 dBm min. over temp. DC Power Input: 24V (+12 - 30V) Input Connector: N-Type Weight: 500g NJT8304N Mechanical Drawing NJT8304N General Specifications Output Interface Waveguide, WR-75… Continue reading New Japan Radio NJT8304N 4W Standard Ku-Band BUC

VSATplus Product Website

New Japan Radio NJT8304F 4W Standard Ku-Band BUC

NJRC NJT8304UF 4W Standard Ku-Band BUC Output Frequency Range: 14.0 - 14.5 GHz L.O. Frequency: 13.05 GHz IF Input Frequency: 950 - 1,700 MHz Output Power @ P1dB: +36.0 dBm min. over temp. DC Power Input: 24V (+12 - 30V) Input Connector: F-Type Weight: 500g NJT8304F Mechanical Drawing NJT8304F General Specifications Output Interface Waveguide, WR-75 with… Continue reading New Japan Radio NJT8304F 4W Standard Ku-Band BUC

VSATplus Product Website

New Japan Radio NJT8302UN 3W Ku-Band Universal BUC

NJRC NJT8302UN 3W Universal Ku-Band BUC Features Output Frequency Range: 13.75 to 14.5 GHz L.O. Frequency: 12.80 GHz IF Input Frequency: 950 to 1,700 MHz Output Power @ P1dB: +34.0 dBm min. over temp. DC Power Input: 24V (+12 - +30V) @ 23W max via input Input Connector: N-type Weight 0.77 Lbs. (350g) NJT8302N Mechanical… Continue reading New Japan Radio NJT8302UN 3W Ku-Band Universal BUC

VSATplus Product Website

New Japan Radio NJT8302UF 3W Ku-Band Universal BUC

NJRC NJT8302UF 3W Universal Ku-Band BUC Features Output Frequency Range: 13.75 to 14.5 GHz L.O. Frequency: 12.80 GHz IF Input Frequency: 950 to 1,700 MHz Output Power @ P1dB: +34.0 dBm min. over temp. DC Power Input: 24V (+12 - +30V) @ 23W max via input Input Connector: F-type Weight 0.77 Lbs. (350g) NJT8302F Mechanical… Continue reading New Japan Radio NJT8302UF 3W Ku-Band Universal BUC

VSATplus Product Website

New Japan Radio NJT8302N 3W Standard Ku-Band BUC

NJRC NJT8302N 3W STANDARD KU-BAND BUC (14.0 to 14.5 GHz) FEATURES Output Frequency Range: 14.0 to 14.5 GHz LO Frequency: 13.05 GHz IF Input Frequency: 950 to 1,450 MHz Output Power @ P1dB: +34.0 dBm min. over temp. DC Power Input: 24V (+12 - +30V) @ 23W max via input Input Connector: N-type Weight 0.77 Lbs.… Continue reading New Japan Radio NJT8302N 3W Standard Ku-Band BUC

VSATplus Product Website

New Japan Radio NJT8302F 3W Standard Ku-Band BUC

NJRC NJT8302F 3W STANDARD KU-BAND BUC (14.0 to 14.5 GHz) FEATURES Output Frequency Range: 14.0 to 14.5 GHz LO Frequency: 13.05 GHz IF Input Frequency: 950 to 1,450 MHz Output Power @ P1dB: +34.0 dBm min. over temp. DC Power Input: 24V (+12 - +30V) @ 23W max via input Input Connector: F-type Weight 0.77 Lbs.… Continue reading New Japan Radio NJT8302F 3W Standard Ku-Band BUC

VSATplus Product Website

New Japan Radio NJT8301UN 1.5W Universal Ku-Band BUC

NJRC NJT8301UN 1.5W KU-BAND (13.7 TO 14.5 GHZ) BUC RF Frequency: 13.75 to 14.5 GHz (Universal Ku-Band) Output Interface: Waveguide, WR75 with Groove Input Interface: N-type, female (50 ohm) Output Power @ 1dB G.C.P.: +31 dBm min. over temperature Linear Gain: 55 dB typ., 48 dB min. Power Requirement: DC Power, +24 V (Range: +12… Continue reading New Japan Radio NJT8301UN 1.5W Universal Ku-Band BUC
