Nexgenwave NEX-300 Series C-Band Int. Ref. PLL LNB Model No.Input Freq. (GHz)Output Freq. (MHz)L.O. Freq. & StabilityNEX-3053.4 – 4.2950 – 17505.15 GHz +/- 5 KHzNEX-3103.4 – 4.2950 – 17505.15 GHz +/- 10 KHzNEX-3253.4 – 4.2950 – 17505.15 GHz +/- 25 KHz Mechanical Drawing SPECIFICATIONS Nexgenwave NEX-300 Series C-Band Int. Ref. PLL LNB Datasheet
Nexgenwave BT-DC1700M Bias Tee
Nexgenwave BT-DC1700M Bias Tee Bandwidth 950MHz to 1.7GHz IF Passed ThroughHigh Stability (10ˉ8)10MHz InjectionUp to 6 Amps DC input15-64 VDC Power input“N” or “F” RF Interface OptionsTwo years WarrantyRoHS Compliance This small and efficient unit provides DC supply and high stability(10ˉ8 )a VSAT(DC power support separate) in case a modem neither cannot supply sufficient power nor 10MHz reference.… Continue reading Nexgenwave BT-DC1700M Bias Tee
Nexgenwave 12Ghz Waveguide Filter (Model No. I12WF00100)
Nexgenwave 12Ghz Waveguide Filter (Model No. I12WF00100) 950MHz to 1.7GHz Bandwidth Waveguide Band Rejection FilterRejection Band 12.75 - 13.25GhzPass Band 11.7-12.25 GhzDimension 165(L) x 38(W) x 38(H)mm Mechanical Drawing ParametersSpecificationsCenter Frequency11.7GHz – 12.25GHzBandwidth550MHzInsertion Loss0.5dB Max.VSWR1.2 maxRejection 12.75 – 13.25GHz75dB Min.IN/OUT PortWR75ColorWhiteSize (mm)165x38x38Weight (kg)0.2Humidity100%
iDirect Service via Eutelsat E70B on 70.5° East Ku-Band
Located at 70.5° East, an orbital position at the crossroad of four continents, EUTELSAT 70B offers a broad Widebeam coverage and four high-performance fixed beams focused over Europe, Africa, Central Asia, South-East Asia and Australia. The satellite’s high degree of on-board connectivity enables beams to be used for both regional and intercontinental connectivity. This supports… Continue reading iDirect Service via Eutelsat E70B on 70.5° East Ku-Band
iDirect Service via T12Vantage Africa beam Ku-band
State-of-the-art high throughput satellite that seamlessly connects the Americas to Europe, Africa and the Middle East. Telstar VANTAGE satellites deliver improved coverage and flexibility to meet the growing communications needs of broadcast, enterprise, government and mobility users. With the Telstar 12 VANTAGE high throughput satellite (HTS), customers can access a combination of broad regional beams… Continue reading iDirect Service via T12Vantage Africa beam Ku-band
iDirect Service via Telstar 11N Ku-band on 37.5° West
The Telstar 11N satellite covers all of Africa except the North. Especially East and South Africa are well covered with high signal values.
iDirect Service via Hylas2 KA – Afghanistan
The HYLAS 2 satellite carries 24 active Ka-band user beams and six gateway beams. The Ka-band spot beams are providing two-way communications services to facilitate high-speed delivery of data to end-user applications such as corporate networking, broadband Internet access, business continuity services and video distribution. Using the HYLAS 2 spacecraft, VSATplus will provide its data… Continue reading iDirect Service via Hylas2 KA – Afghanistan
iDirect Service via Hylas2 KA – Libya
The HYLAS 2 Ka-band over Libya is providing two-way communications services to facilitate high-speed delivery of data to end-user applications such as corporate networking, broadband Internet access, business continuity services and video distribution.
iDirect Service in Ka-Band via Hylas2 KA – Iraq-Syria beam
The HYLAS 2 satellite carries 24 active Ka-band user beams and six gateway beams. The Ka-band spot beams are providing two-way communications services to facilitate high-speed delivery of data to end-user applications such as corporate networking, broadband Internet access, business continuity services and video distribution. Using the HYLAS 2 spacecraft, NYNEX will provide its data… Continue reading iDirect Service in Ka-Band via Hylas2 KA – Iraq-Syria beam
iDirect Service Ku-Band via NSS-12 on 57° East
The SES Worldskies NSS12 KU band satellite is covering nearly all of Europe, the West Middle East and North as well as East Africa. This beam has a very strong signal coverage and reaches the highest modulation. Especially our customers from Iraq and Lybia are very satisfied with this beam.
