The rapid advancement of robotics and artificial intelligence is transforming industries worldwide. Organizations are increasingly looking for intelligent robotic platforms capable of operating in environments that are difficult, dangerous, or inefficient for human workers. Whether performing industrial inspections, supporting emergency response teams, conducting security patrols, or assisting in defense operations, autonomous quadruped robots are becoming an essential part of modern field operations.
The Norsat GQR0116 Intelligent Quadruped Robot – Special Edition represents the next generation of mobile robotic technology. Designed with advanced sensing systems, AI-powered navigation, high-performance computing, and rugged mechanical engineering, the GQR0116 is capable of traversing complex terrain while carrying payloads and performing intelligent autonomous tasks.
Combining mobility, durability, and artificial intelligence, the GQR0116 is suitable for industrial automation, smart inspection, public safety, research, defense, and infrastructure monitoring. According to the product datasheet, it offers intelligent obstacle avoidance, a super-wide-angle 3D LiDAR system, optional NVIDIA Jetson Orin AI computing, IP67 protection, and speeds of up to 5 m/s.
At VSATplus, organizations can order the Norsat GQR0116 Intelligent Quadruped Robot with expert technical consultation, worldwide delivery, and professional support for robotics and advanced communication projects.
The GQR0116 is a four-legged autonomous robotic platform engineered to perform tasks that would otherwise require human operators in hazardous or inaccessible environments.
Unlike traditional wheeled robots, the quadruped design enables the robot to move across:
Its sophisticated AI algorithms allow the robot to perceive its surroundings, avoid obstacles, follow operators, and execute programmable missions with minimal human intervention.
The GQR0116 incorporates intelligent navigation capabilities designed for autonomous operation.
According to the specification sheet, the robot includes:
These features allow users to deploy the robot in both autonomous and operator-controlled scenarios.
Modern robotic applications require significant onboard computing power.
The GQR0116 includes:
| Component | Specification |
|---|---|
| Standard CPU | 8-Core High-Performance Processor |
| Optional AI Module | NVIDIA Jetson Orin |
| AI Computing Performance | 40–100 TOPS |
With optional NVIDIA Jetson Orin integration, developers can deploy advanced AI workloads such as:
One of the robot’s most powerful technologies is its integrated:
Super-Wide-Angle 3D LiDAR
This enables:
The LiDAR system allows reliable navigation in dynamic indoor and outdoor environments.
The robot includes a comprehensive sensing system for environmental awareness.
Integrated sensors help provide:
This sensor suite enables stable movement over uneven surfaces while supporting autonomous navigation.
Unlike conventional robots, the quadruped design offers exceptional mobility.
| Parameter | Specification |
|---|---|
| Maximum Speed | 5 m/s |
| Normal Speed | 0–3.7 m/s |
| Climbing Angle | 40° |
| Maximum Step Height | Approximately 16 cm |
| Maximum Payload | 12 kg |
These capabilities enable operation across demanding terrain where wheeled robots cannot function effectively.
The GQR0116 is designed for extended field missions.
| Parameter | Specification |
|---|---|
| Battery Capacity | 15,000 mAh |
| Operating Voltage | 28–33.6V |
| Battery Endurance | 2–4 Hours |
| Charger | Fast Charge (33.6V / 9A) |
Long battery life minimizes downtime and increases operational productivity.
Despite weighing only 15 kg, the robot supports:
Up to 12 kg payload capacity
This allows integration of:
The robot’s articulated leg system provides outstanding mobility.
| Joint | Motion Range |
|---|---|
| Body | -48° to 48° |
| Thigh | -200° to 90° |
| Shank | -156° to -48° |
The robot incorporates:
These powerful actuators provide stability, balance, and climbing capability.
The GQR0116 supports modern wireless communication technologies.
Available communication features include:
These connectivity options allow remote monitoring and integration with enterprise networks.
| Parameter | Specification |
|---|---|
| Weight | 15 kg (Battery Included) |
| Material | Aluminum Alloy + High-Strength Engineering Plastic |
| Standing Length | 700 mm |
| Standing Width | 310 mm |
| Standing Height | 400 mm |
| Lying Length | 760 mm |
| Lying Width | 310 mm |
| Lying Height | 200 mm |
The lightweight yet durable construction enables deployment in both industrial and outdoor environments.
Industrial robots must withstand challenging operating conditions.
The GQR0116 provides:
| Parameter | Specification |
|---|---|
| IP Rating | IP67 |
IP67 protection provides resistance against:
This makes the robot suitable for all-weather field operations.
According to the datasheet, the robot includes:
These capabilities simplify software maintenance while allowing developers to customize robotic applications.
The GQR0116 can autonomously inspect:
The robot supports:
Suitable for:
The robot can assist first responders by entering dangerous environments before human personnel.
Typical missions include:
Ideal for inspecting:
Universities and robotics laboratories can utilize the GQR0116 for:
✔ AI-powered autonomous navigation
✔ Optional NVIDIA Jetson Orin (40–100 TOPS)
✔ Super-wide-angle 3D LiDAR
✔ Intelligent obstacle avoidance
✔ Wi-Fi 6 and 4G connectivity
✔ 12 kg payload capacity
✔ IP67 environmental protection
✔ Up to 5 m/s maximum speed
✔ 40° climbing capability
✔ 15,000 mAh battery
✔ Graphical programming
✔ OTA software updates
✔ Secondary software development support
✔ Industrial-grade aluminum construction
VSATplus supplies advanced satellite communication systems, robotics platforms, AI-enabled technologies, and mission-critical equipment to customers around the world.
When purchasing the Norsat GQR0116 from VSATplus, customers benefit from:
Whether you’re deploying autonomous inspection systems, enhancing industrial automation, or implementing next-generation robotic solutions, VSATplus can help deliver the right equipment for your mission.
The Norsat GQR0116 Intelligent Quadruped Robot – Special Edition is a highly capable autonomous robotic platform designed for organizations requiring intelligent mobility, AI-powered decision-making, and reliable performance in challenging environments.
With advanced navigation, optional NVIDIA Jetson Orin AI computing, super-wide-angle 3D LiDAR, IP67 environmental protection, 12 kg payload capacity, and high-speed mobility, the GQR0116 is an ideal solution for industrial inspections, defense, security, emergency response, and research applications.
Available now from VSATplus, the Norsat GQR0116 offers a powerful combination of artificial intelligence, rugged engineering, and autonomous mobility for the next generation of field robotics.
