The Novra S300E DVB-S2 Receiver/Router from Novra Technologies is a compact, professional-grade IP satellite receiver designed for reliable and efficient delivery of IP data over DVB-S and DVB-S2 satellite networks. Built for enterprise, broadcast, government, and telecom applications, the S300E combines advanced DVB-S2 demodulation, IP routing, and high-speed Ethernet connectivity into a highly reliable platform.
As modern satellite networks increasingly focus on IP-based delivery, organizations require equipment capable of:
The Novra S300E is engineered specifically to meet these demands.
At VSATplus, we provide the Novra S300E along with technical guidance, deployment support, and global delivery services—helping customers build reliable satellite IP infrastructures that perform in real-world conditions.
Satellite communication has evolved from traditional video broadcasting into advanced IP-based data delivery.
Today’s satellite infrastructures support:
These applications require:
The Novra S300E addresses these needs by combining:
Unlike consumer satellite receivers, the S300E is designed specifically for professional IP-over-satellite applications.
This makes it ideal for:
At the heart of the S300E is a professional DVB-S2 demodulator supporting:
Supported modulation formats include:
This enables:
The ability to support advanced modulation schemes makes the S300E suitable for modern high-throughput satellite networks.
The S300E supports:
The system supports data throughput up to:
This enables efficient delivery of:
The S300E supports both DVB-S and DVB-S2 environments.
Advantages include:
This flexibility is important for operators transitioning from older satellite networks to modern DVB-S2 platforms.
The receiver includes:
This simplifies:
The result is reduced operational complexity and faster setup times.
The S300E supports:
Benefits include:
These features are essential in modern satellite networks where bandwidth optimization directly impacts operational costs.
The unit supports:
This enables:
This capability is especially useful in enterprise and broadcast satellite infrastructures.
The S300E includes built-in LNB management features:
This reduces:
Networking support includes:
This allows integration into:
The S300E is designed for:
Optional mounting:
This makes it practical for:
The S300E includes:
These features improve:
This is especially important for 24/7 enterprise and broadcast operations.
| Parameter | Specification |
|---|---|
| Receiving Frequency | 950 to 2150 MHz |
| Frequency Acquisition | ±10 MHz above 10 Msps |
| Input Signal Level | -70 dBm to -25 dBm |
| RF Connector | F-Type, 75 Ohm |
| Modulation Type | Symbol Rate |
|---|---|
| DVB-S QPSK | 100 Ksps to 45 Msps |
| DVB-S2 QPSK | 100 Ksps to 45 Msps |
| DVB-S2 8PSK | 100 Ksps to 45 Msps |
| DVB-S2 16APSK | 100 Ksps to 45 Msps |
| DVB-S2 32APSK | 100 Ksps to 45 Msps |
| Parameter | Specification |
|---|---|
| Data Throughput | Up to 80 Mbps |
| Ethernet Interface | 10/100 Base-T RJ45 |
| Protocols | UDP/IP, IP Multicast |
| IGMP Support | V1.0, V2.0 |
| Standard | Supported Rates |
|---|---|
| DVB-S | 1/2, 2/3, 3/4, 5/6, 6/7, 7/8 |
| DVB-S2 | 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 |
| Parameter | Specification |
|---|---|
| Height | 1.41 in (3.58 cm) |
| Width | 5.22 in (13.26 cm) |
| Depth | 4.10 in (10.42 cm) |
| Weight | 1 lb (0.46 kg) |
| Parameter | Specification |
|---|---|
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -55°C to 85°C |
| Humidity | 10% to 90% Non-Condensing |
| Standard | Compliance |
|---|---|
| DVB | ETSI 301.192 |
| MPEG | ISO/IEC 13818 |
| Ethernet | IEEE 802.3 |
| Safety | EN 60950 |
| EMC | EN 55022 / EN 55024 |
| Certifications | FCC / Industry Canada |
Supports advanced modulation schemes for improved bandwidth utilization.
Easy to deploy in enterprise and broadcast environments.
Built specifically for professional IP-over-satellite applications.
Supports desktop and rackmount installations.
Integrates seamlessly into modern IP infrastructures.
Suitable for continuous 24/7 operations.
Satellite-based IP delivery remains critical for:
Traditional terrestrial networks cannot always provide:
The S300E solves this by enabling:
As organizations continue expanding into hybrid satellite-IP architectures, professional receivers like the S300E remain essential infrastructure components.
Deploying satellite communication infrastructure requires technical expertise—not just hardware.
At VSATplus, we provide:
We help customers:
Whether you are operating a broadcast network, enterprise WAN, IPTV platform, or government communication system, VSATplus can support your project from planning through deployment.
The Novra S300E DVB-S2 Receiver/Router is a compact yet powerful professional solution for IP-over-satellite connectivity. Combining advanced DVB-S2 reception, high-speed IP delivery, professional networking features, and carrier-grade reliability, the S300E provides a flexible and efficient platform for modern satellite communication infrastructures.
Its support for:
makes it highly suitable for enterprise, broadcast, telecom, and government applications.
With VSATplus, customers gain access not only to the Novra S300E hardware, but also to the technical expertise and deployment support necessary to ensure reliable real-world satellite network performance.
