The LS2150A Series by Quintech Electronics is a high-performance line of active (zero-loss) L-band RF splitters designed to meet the demands of modern RF distribution systems in satellite ground stations, data centers, test labs, and teleport facilities. Supporting a frequency range of 950–2150 MHz, this series offers scalable configurations from 4-way to 64-way with exceptional signal integrity, power handling, and mechanical reliability.

Offered by VSATPlus, the LS2150A line is a flexible, rack-mounted solution for cleanly splitting L-band signals with zero insertion loss, full LNB powering, and multiple RF connector and impedance options. With Quintech's proprietary microstrip design, these splitters provide superior isolation and return loss characteristics, making them ideal for broadcast, SATCOM, and test environments.

✨ Key Features & Highlights

• Active (Amplified) Splitters with Zero Insertion Loss
• Frequency range: 950 to 2150 MHz
• Available in 1x4, 1x8, 1x12, 1x16, 1x24, 1x32, 1x48, and 1x64 configurations
• F-Type or BNC connectors with 50Ω or 75Ω impedance
• 18 VDC LNB power supported via input
• Consistent insertion loss of 0 ± 2 dB
• Rackmount: 1RU, 2RU, or 3RU depending on configuration
• DC blocked on all output ports for protection
• Microstrip board design ensures low P1dB distortion and excellent frequency flatness
• Dual power options: 18–24 VDC and 100–240 VAC

📊 Technical Specifications Summary

⚙️ Electrical and Mechanical Specs

• Power Options: 18–24 VDC (via 2-pin quick connect) or 100–240 VAC (50/60 Hz)
• LNB Power Pass: 18 VDC from input port to LNB
• Connector Options: F-Type or BNC (specify 50Ω or 75Ω)
• Mounting: 19” rack standard (varies by port count)
• Output Ports: All outputs DC blocked
• Frequency Flatness: ±1 dB (LS04, LS08); ±2 dB (others)
• Spurious Level: Better than -55 dBc/4KHz typical

📅 Use Case Applications

• Broadcast & Headend Facilities: Centralized signal distribution to encoders or receivers
• VSAT & Satellite Earth Stations: RF signal fanout to modems or analyzers
• RF Test & Measurement Labs: Precision signal distribution for parallel analysis
• Satellite Gateways: Uplink/downlink signal routing to multiple monitoring chains
• Mobile Ground Stations: Clean RF distribution in OB vans or portable racks

💡 Key Benefits

• Zero Insertion Loss: No attenuation of RF signal across outputs
• Microstrip Circuit Design: Stable amplitude/phase, minimal temperature drift
• LNB Support: Simplified design with power pass-through on input
• Improved Cable Management: One splitter instead of daisy-chained passive devices
• No Need for Amplifiers: Maintains signal levels across high-output configurations
• Reduces Failures: No frequent connecting/disconnecting of RF cables

🛒 Order from VSATPlus

VSATPlus is proud to distribute the full line of Quintech LS2150A active L-band splitters.

When you order from VSATPlus, you get:

• Official, certified hardware
• Expert integration support
• Global shipping and rack-mount ready configurations
• Fast response and technical consultation

📞 Contact VSATPlus today to order LS2150A models that fit your RF infrastructure perfectly.

🌟 Conclusion: Scalable RF Splitting Without Compromise

With the LS2150A Series, Quintech delivers industrial-grade, zero-loss signal splitting across a wide range of port configurations. Designed for maximum uptime and minimal distortion, these splitters simplify cable management, power LNBs, and reduce network complexity. Whether you need a compact 1x4 solution or a full 1x64 fan-out for a teleport, this series has you covered.
